Pin
No.
Port Name Function Name
Related Power Supply
Detail of FunctionON OFF
I/O Logic I/O Logic
121
A4/[A4/D4]/AN2_4/
P2_4/N_CTS10/N_
RTS10
A[4] B Bus O Low External bus
122
A3/[A3/D3]/AN2_3/
P2_3/TXD9
A[3] B Bus O Low External bus
123
A2/[A2/D2]/AN2_2/
P2_2/RXD9
A[2] B Bus O Low External bus
124
A1/[A1/D1]/BC2/
[BC2/D1]/AN2_1/
P2_1/CLK9
A[1] B Bus O Low External bus
125
A0/[A0/D0]/BC0/
[BC0/D0]/AN2_0/
P2_0/N_CTS9/N_
RTS9
A[0] B Bus O Low External bus
126
D15/N_INT5/IIO0_7/
IIO1_7/P1_7
D[15] B Bus I --- External bus
127
D14/N_INT4/IIO0_6/
IIO1_6/P1_6
D[14] B Bus I --- External bus
128
D13/N_INT3/IIO0_5/
IIO1_5/P1_5
D[13] B Bus I --- External bus
129
D12/IIO0_4/IIO1_4/
P1_4
D[12] B Bus I --- External bus
130
D11/IIO0_3/IIO1_3/
P1_3
D[11] B Bus I --- External bus
131
D10/IIO0_2/IIO1_2/
P1_2
D[10] B Bus I --- External bus
132
D9/IIO0_1/IIO1_1/
P1_1
D[9] B Bus I --- External bus
13
3
IIO0_0/IIO1_0/D8/
P1_0
D[8] B Bus I --- External bus
134 AN0_7/D7/P0_7 D[7] B Bus I --- External bus
135 AN0_6/D6/P0_6 D[6] B Bus I --- External bus
136 AN0_5/D5/P0_5 D[5] B Bus I --- External bus
137 AN0_4/D4/P0_4 D[4] B Bus I --- External bus
138 P19_1 FPGA_N_CFG O L act O Low FPGA nCONF
139 WR3/BC3/P11_4 FPGA_N_STA I L act I --- FPGA nSTATUS
140 P19_0 FPGA_CDONE I H act I --- FPGA CONF DONE
141
IIO1_3/N_RTS8/N_
CTS8/WR2/CS3/
P11_3
--- O Low O Low No used
142
IIO1_2/RXD8/CS2/
P11_2
NCPU_MISO I Data O Low Network microprocessor UART reception data
143
IIO1_1/CLK8/CS1/
P11_1
SPRY_Z2&FP O H act O Low SP relay Zone2 and Front Presence
144
IIO1_0/TXD8/CS0/
P11_0
NCPU_MOSI O Data O Low Network microprocessor UART transmission data
145 P18_7 HPRY O H act O Low HP relay
146 P18_6 MT_N_Z2 O L act O Low Mute Zone2 (Line out)
147 P18_5 --- O H act O Low No used
148 P18_4 MT_N_5CH O L act O Low Mute 5ch (L, C, R, SRL, SRR Preout/Main amplifier input)
149 P18_3 MT_N_SW O L act O Low Mute Subwoofer (Preout)
150 P18_2 MT_N_SB O L act O Low Mute SB/BA/Z2/FP (Preout/Main amplifier input)
151 AN0_3/D3/P0_3 D[3] B Bus I --- External bus
152 AN0_2/D2/P0_2 D[2] B Bus I --- External bus
153 AN0_1/D1/P0_1 D[1] B Bus I --- External bus
154 AN0_0/D0/P0_0 D[0] B Bus I --- External bus
155
IIO0_7/N_R
TS6/
N_CTS6/N_SS6/
AN15_7/P15_7
SVID_DET I H act I --- S-video detect
156
IIO0_6/CLK6/
AN15_6/P15_6
HP_N_DET I L act O Low Headphone detection
157
IIO0_5/RXD6/SCL6/
STXD6/AN15_5/
P15_5
EX1_N_CS O L act O Low Expansion IO 1 chip select
75
