■ MECHANICAL PARTS
37
RX-E100
RX-E100
Ref.
No. PART NO. Description Remarks Markets
New Parts
*
! 1- 1 V4193900 P.C.B. ASS’Y SI:OPERATION
* 1-10 MF120160 FLEXIBLE FLAT CABLE 20P 160mm
* 1-11 V3685500 FRONT PANEL SI (UCRA)
* 1-11 V3685600 FRONT PANEL SI (BG)
* 1-11 V3809500 FRONT PANEL GD (UCRA)
* 1-11 V3809600 FRONT PANEL GD (BG)
* 1-12 V3686800 SUB PANEL-RX SI
* 1-12 V3810400 SUB PANEL-KX GD
* 1-13 V3687400 PANEL, SIDE-H81
* 1-14 V3687900 SHEET, WINDOW-RX
1-20 VQ368600 PUSH RIVET P3555-B
1-21 VF617600 PAN HEAD P-TITE SCREW 2.6x8 FCRM3-BL
* 2- 1 V4217700 P.C.B. ASS’Y MAIN (UC)
* 2- 1 V4217800 P.C.B. ASS’Y MAIN (R)
* 2- 1 V4217900 P.C.B. ASS’Y MAIN (A)
* 2- 1 V4218000 P.C.B. ASS’Y MAIN (B)
* 2- 1 V4218100 P.C.B. ASS’Y MAIN (G)
2- 2 V5000200 P.C.B. ASS’Y TU-03 (UCR)
2- 2 V5000300 P.C.B. ASS’Y TU-03 (A)
2- 2 V5000400 P.C.B. ASS’Y TU-03 (BG)
2- 8 V4804400 EARTH CLIP ASSY 1P 50mm (UC)
* 2-11 V3685300 HEAT SINK
* 2-12 V3685000 SUPPORT, HS-L
* 2-13 V3685100 SUPPORT, HS-R
* 2-14 V3685200 SUPPORT, REAR
2-15 VV849300 SHEET 19x24
2-20 VQ368500 PUSH RIVET P3545-B
2-21 VK173200 SCREW, TRANSISTOR 3x15 SP FCM3
2-22 EP600830 BIND HEAD B-TITE SCREW 3x8 FCRM3-BL
2-23 EG330030 BIND HEAD SCREW 3x6 FCRM3-BL
2-24 VT669300 PW HEAD B-TITE SCREW 3x8-8 MFC2 (UC)
Z * 10 XW338A00 POWER TRANSFORMER (U)
Z * 10 XW339A00 POWER TRANSFORMER (C)
Z * 10 XW340A00 POWER TRANSFORMER (R)
Z * 10 XW341A00 POWER TRANSFORMER (A)
Z * 10 XW342A00 POWER TRANSFORMER (BG)
Z 11 V2296800 POWER CORD ASS’Y (A)
Z 11 V2363800 POWER CORD ASS’Y (UC)
Z 11 VN363700 POWER CORD ASS’Y (G)
Z 11 VV437300 POWER CORD ASS’Y (B)
Z 11 VZ542500 POWER CORD ASS’Y(R)
12 V2438700 CORD STOPPER ’10P1
13 VU590000 BINDING TIE CBTD001B
15 VB933800 FERRITE CORE BP53RB310190NOA (BG)
16 VZ625600 BINDING TIE SE140 L=140 (UCABG)
20 VV272500 DC FAN MOTOR 2410ML-05W-B20-L00
* 101 V3681600 TOP COVER SI
* 101 V3809100 TOP COVER GD
* 102 V3684400 CHASSIS
* 103 V3682000 REAR PANEL (U)
* 103 V3682100 REAR PANEL (C)
* 103 V3682200 REAR PANEL (R)
* 103 V3682300 REAR PANEL (A)
