Yamaha RX-E100 - EXPLODED VIEW

■ EXPLODED VIEW
36
ABCDE
1
2
3
4
5
6
7
RX-E100
! : Note on the Operation PCB
Of the Operation PCB(1-1) part Nos., only the silver (SI) type part Nos. are included in the table.
The only different part between the gold (GD) and silver (SI) type parts is the sheet/FL that is attached to the
fluorescent character display tube. When a GD type Operation PCB becomes necessary, order a SI type Operation
PCB and a GD type sheet/FL (VR519500) and replace the sheet/FL of the SI type Operation PCB with the GD type
sheet/FL.
