Yamaha RX-E400 - P.C.B. Operation

RX-E400
22
RX-E400
P.C.B. OPERATION
Schm
Ref. PARTNO. Description Market
NewParts
*
Schm
Ref. PARTNO. Description Market
NewParts
*
% : Note on the Operation PCB
Of the Operation PCB part Nos., only the silver (SI) type part Nos.
are included in the table.
The only different part between the gold (GD) and silver (SI) type
parts is the sheet/FL that is attached to the fluorescent character
display tube. When a GD type Operation PCB becomes necessary,
order a SI type Operation PCB and a GD type sheet/FL (VR519500)
and replace the sheet/FL of the SI type Operation PCB with the GD
type sheet/FL.
* V9333900 P.C.B. SI:OPERATION
CB701 VP682200 CN.BS.PIN 8P
CB705 Vi878300 CN.BS.PIN 5P
CB706 Vi878900 CN.BS.PIN 11P
CB707 VU281700 CN 17P
C700 US062680 C.CE.M.CHP 680pF50V
C701 US062680 C.CE.M.CHP 680pF50V
C702 US061220 C.CE.M.CHP 22pF50V
C703 US061220 C.CE.M.CHP 22pF50V
C704 US135100 C.CE.CHP 0.1uF16V
C705 US135100 C.CE.CHP 0.1uF16V
C707 UM416220 C.EL 2.2uF50V
C708 UM397100 C.EL 10uF16V
C709 US135100 C.CE.CHP 0.1uF16V
C710 VE326100 C.MYLAR.ML 0.12uF50V
C711 VE326100 C.MYLAR.ML 0.12uF50V
C712 UM388100 C.EL 100uF10V
C713 UM388100 C.EL 100uF10V
C714 VU545000 C.EL 47000uF5.5V
C715 UA654330 C.MYLAR 0.033uF50V
C716 UA654330 C.MYLAR 0.033uF50V
C717 UM416100 C.EL 1uF50V
C719 US064100 C.CE.M.CHP 0.01uF50V
C720 UM388100 C.EL 100uF10V
C721 UA654100 C.MYLAR 0.01uF50V
C722 US064100 C.CE.M.CHP 0.01uF50V
C723 UA654100 C.MYLAR 0.01uF50V
C724 UM416220 C.EL 2.2uF50V
C725 UA654100 C.MYLAR 0.01uF50V
D701 VU171900 DIODE.ZENR UDZ5.1B5.1V
D702 VT332900 DIODE 1SS355
D703 VU171900 DIODE.ZENR UDZ5.1B5.1V
D704 VR711400 LED(gr) SLR‑325MC
D705 VU171900 DIODE.ZENR UDZ5.1B5.1V
D706 VT332900 DIODE 1SS355
D707 VT332900 DIODE 1SS355
D708 VT332900 DIODE 1SS355
D709 VT332900 DIODE 1SS355
D710 VU172100 DIODE.ZENR UDZS6.2B6.2V
D711 VU172100 DIODE.ZENR UDZS6.2B6.2V
* IC700 X2898A00 IC.CPU M30217M8‑A103FP
JK700 V3589000 JACK.MNI HTJ‑035‑18EBGT
Q700 VD678500 TR.DGT DTA114ES
Q701 VV655700 TR.DGT DTC144EKA
Q702 VP872700 TR 2SC4488S,T
Q703 VV556500 TR 2SA1037KQ,R,S
ST701 V4040500 SCR.TERM M3
* SW700 V9291700 SW.RT.ENC XREB12105PVB25F
SW701 V2014900 SW.TACT EVQ21304M
SW702 V2014900 SW.TACT EVQ21304M
SW703 V2014900 SW.TACT EVQ21304M
SW704 V2014900 SW.TACT EVQ21304M
SW705 V2014900 SW.TACT EVQ21304M
SW706 V2014900 SW.TACT EVQ21304M
SW707 V2014900 SW.TACT EVQ21304M
U700 V3872300 L.DTCT PIC‑28143TH5
V700 V3579300 FL.DSPLY 16‑BT‑67GN
VR700 V3555600 VR B20KΩ
VR701 V3555700 VR W25KΩ
VR702 V3555800 VR MN100KΩ
XL700 VQ328900 RSNR.CRYS 32.768KHz
XL701 V7718300 RSNR.CE CSTLS10M0G53‑B0
V3688300 SHEET.FL SI
% VR519500 SHEET.FL GD
V3747400 SPACER.FL T4x6x18
V3747500 SUPRT
RD353220 R.CAR.CHP 2.2Ω1/10W
RD355100 R.CAR.CHP 100Ω1/10W
RD355220 R.CAR.CHP 220Ω1/10W
RD355270 R.CAR.CHP 270Ω1/10W
RD355390 R.CAR.CHP 390Ω1/10W
RD355470 R.CAR.CHP 470Ω1/10W
RD356100 R.CAR.CHP 1KΩ1/10W
RD356180 R.CAR.CHP 1.8KΩ1/10W
RD356220 R.CAR.CHP 2.2KΩ1/10W
RD356470 R.CAR.CHP 4.7KΩ1/10W
RD356560 R.CAR.CHP 5.6KΩ1/10W
RD356680 R.CAR.CHP 6.8KΩ1/10W
RD357100 R.CAR.CHP 10KΩ1/10W
RD357220 R.CAR.CHP 22KΩ1/10W
RD357330 R.CAR.CHP 33KΩ1/10W
RD357470 R.CAR.CHP 47KΩ1/10W
RD358100 R.CAR.CHP 100KΩ1/10W
RD358220 R.CAR.CHP 220KΩ1/10W
