Yamaha RX-Z9 Service Manual

RX-Z9/DSP-Z9
36
RX-Z9/DSP-Z9
When there is a history of protection function:
The FL display appears as shown below depending on the
type of the protection function.
プロテクション履歴がある場合:
スピーカーをショートさせた時などが原因で、
プロテクションが働いたことを示します。
アンプの故障でスピーカーに直流電圧が掛
かるなどが原因で、プロテクションが働い
たことを示します。異常状態のままパワー
オンすると、約4秒後にプロテクションが掛
かり、電源が切れます。
電源電圧による原因で、プロテクションが
働いたことを示します。異常状態のままパ
ワーオンすると、約1.5秒後にプロテクショ
ンが掛かり、電源が切れます。
温度制限を越えた原因で、プロテクション
が働いたことを示します。異常状態のまま
パワーオンすると、約2秒後にプロテクショ
ンが掛かり、電源が切れます。
The protection function worked due to exces-
sive current through the amplifier. Causes
could be a short at the speaker terminal or a
defect in the amplifier. The protection func-
tion activates immediately to turn off the
power, with no history display at turn-on, if
the amplifier is defective.
The protection function worked due to a DC
voltage appearing at the speaker terminal.
A cause could be a defect in the amplifier. If
the power is turned on with the abnormality
unsolved, the protection function works in
about 4 seconds to turn off the power.
The protection function worked due to a de-
fect or overload in the power supply. If the
power is turned on with the abnormality un-
solved, the protection function works in about
1.5 seconds to turn off the power.
The protection function worked due to the
temperature limit being exceeded. Causes
could be poor ventillation or a defect related
to the thermal sensor. If the power is turned
on with the abnormality unsolved, the pro-
tection function works in about 2 seconds to
turn off the power.
プロテクションの種類によって下記の表示が現れます。
各プロクテクションの検出に関しては、後述のダイアグメ
ニューNo.19AD/FAN（64ページ）を参照してください。
● History of protection function
When the protection function has worked, its history is stored
in memory with a backup. Even if no abnormality is noted while
servicing the unit, an abnormality which has occurred previ-
ously can be defined as long as the backup data has been
stored.
The history of the protection function is cleared when DIAG is
cancelled by selecting PRESET RESERVED (Memory initial-
ized) of DIAG menu No.18 or when the backup data is erased.
●プロテクションの履歴
プロテクションが働いた場合、履歴をバックアップして記憶していま
す。サービスのときに異常が認められなくても、バックアップが残って
いれば、お客様のところで起きた異常を区別できます。
ダイアグメニュー No.18 で PRESETRESERVED（メモリーの初期化）
を選んでダイアグを解除した場合、またはバックアップが消えた場合
に、プロテクションの履歴はクリアされます。
I PROTECT:xx
VER M/V/D=B/E/G
TMPx PROTECT:xx
VER M/V/D=B/E/G
PSx PROTECT:xx
VER M/V/D=B/E/G
DCx PROTECT:xx
VER M/V/D=B/E/G
For detection of each protection function (except I-PROTECT)
, refer to DIAG MENU No.19 AD/FAN (p.64).

Yamaha RX-Z9 Specifications

General

Package weight	34110 g
Package depth	470 mm
Package height	211.13 mm
Receiver type	Surround
RMS rated power	1290 W
Pre-out connectivity	Yes
Audio output channels	9.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.005 %
Dynamic power per channel (4 Ohm)	340 W
Dynamic power per channel (8 Ohm)	210 W
Power output per channel (1KHz@8 Ohm)	170 W
RS-232 ports	1
12V trigger ports quantity	2
Speakers connectivity type	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Damping factor	200
Volume control	Rotary
Number of products included	1 pc(s)
S-Video inputs quantity	8
Component video (YPbPr/YCbCr) in	6
Ethernet LAN	No
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Preset stations quantity	40
THX-certified	THX Ultra2
Power consumption (standby)	1 W

Weight and Dimensions

Depth	471 mm
Width	435 mm
Height	211 mm
Weight	30000 g
