Yamaha RX-Z9 Service Manual

RX-Z9/DSP-Z9
8
RX-Z9/DSP-Z9
■ SPECIFICATIONS/参考仕様
AMPLIFIER SECTION / オーディオ部
Minimum RMS Output Power Per Channel / 定格出力
FRONT (20 Hz to 20 kHz, 0.015% THD)
U, C, R, T, K, A, B, G models (8 ohms)
. . . . . .
170 W + 170 W
J model (6 ohms)
. . . . . . . . . . . . . . . . . . . . . .
170 W + 170 W
CENTER (20 Hz to 20 kHz, 0.015% THD)
U, C, R, T, K, A, B, G models (8 ohms)
. . . . . . . . . . . . .
170 W
J model (6 ohms)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
170 W
SURROUND (20 Hz to 20 kHz, 0.015% THD)
U, C, R, T, K, A, B, G models (8 ohms)
. . . . . .
170 W + 170 W
J model (6 ohms)
. . . . . . . . . . . . . . . . . . . . . .
170 W + 170 W
SURROUND BACK (20 Hz to 20 kHz, 0.015% THD)
U, C, R, T, K, A, B, G models (8 ohms)
. . . . . .
170 W + 170 W
J model (6 ohms)
. . . . . . . . . . . . . . . . . . . . . .
170 W + 170 W
PRESENCE (1 kHz, 0.05% THD)
U, C, R, T, K, A, B, G models (8 ohms)
. . . . . . . .
50 W + 50 W
J model (6 ohms)
. . . . . . . . . . . . . . . . . . . . . . . .
50 W + 50 W
Maximum Power (EIAJ) / 実用最大出力
FRONT (1 kHz, 10 % THD)
R, T, K models (8 ohms)
. . . . . . . . . . . . . . . . .
250 W + 250 W
J model (6 ohms)
. . . . . . . . . . . . . . . . . . . . . .
250 W + 250 W
CENTER (1 kHz, 10 % THD)
R, T, K models (8 ohms)
. . . . . . . . . . . . . . . . . . . . . . . .
250 W
J model (6 ohms)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
250 W
SURROUND (1 kHz, 10 % THD)
R, T, K models (8 ohms)
. . . . . . . . . . . . . . . . .
250 W + 250 W
J model (6 ohms)
. . . . . . . . . . . . . . . . . . . . . .
250 W + 250 W
SURROUND BACK (1 kHz, 10 % THD)
R, T, K models (8 ohms)
. . . . . . . . . . . . . . . . . . . . . . . .
250 W
J model (6 ohms)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
250 W
PRESENCE (1 kHz, 10 % THD)
R, T, K models (8 ohms)
. . . . . . . . . . . . . . . . . . .
70 W + 70 W
J model (6 ohms)
. . . . . . . . . . . . . . . . . . . . . . . .
70 W + 70 W
Dynamic Power Per Channel (IHF) (U, C, R, T, K models)
8 ohms
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
210 W + 210 W
6 ohms
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
260 W + 260 W
4 ohms
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
340 W + 340 W
2 ohms
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
580 W + 580 W
DIN Standard Output Power Per Channel (B, G models)
(1 kHz, 0.7 % THD, Stereo, 4 ohms)
FRONT
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
300 W + 300 W
CENTER
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
300 W
SURROUND
. . . . . . . . . . . . . . . . . . . . . . . . . . .
300 W + 300 W
SURROUND BACK
. . . . . . . . . . . . . . . . . . . . . .
300 W + 300 W
PRESENCE
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
90 W + 90 W
IEC Power (B, G models)
1 kHz, 0.015% THD, Stereo, 8 ohms
. . . . . . . . . . . . . . . .
175 W
Power Band Width / パワーバンド幅
0.04% THD, Stereo, 85W/8 ohms
. . . . . . . . . .
10 Hz to 60 kHz
Damping Factor / ダンピングファクタ
20 Hz to 20 kHz, L/C/R, 8 ohms
. . . . . . . . . . . . . .
200 or more
Input Sensitivity/Impedance / 入力感度/インピーダンス
CD, etc. (100W/8 ohms)
. . . . . . . . . . . . . . . .
200 mV/47 k-ohms
PHONO MM (100W/8 ohms)
. . . . . . . . . . . .
3.5 mV/47 k-ohms
FRONT IN (100W/8 ohms)
. . . . . . . . . . . . . . . .
1 V/47 k-ohms
Maximum Input Signal / 最大許容入力
1kHz, 0.05 % THD, CD, etc. (Normal/High)
. . . . . . .
2.4 V/3.0 V
1kHz, 0.05 % THD, PHONO MM (Straight)
. . . . . . . . . . .
75 mV
Output Level/Impedance / 出力電圧/インピーダンス
REC OUT
. . . . . . . . . . . . . . . . . . . . . . . . . .
200 mV/0.5 k-ohms
PRE OUT (FRONT, CENTER, SURROUND, SURROUND BACK, PRESENCE)
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.0 V/0.5 k-ohms
PRE OUT (SUBWOOFER SPLIT, Stereo & Main Small)
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.0 V/1.5 k-ohms
PRE OUT (SUBWOOFER MONO, Stereo & Main Small)
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.0 V/1.5 k-ohms
Maximum Voltage Output / 最大出力
20 Hz to 20 kHz, 1% THD, PRE OUT MAIN L/R
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 V or more
Headphone Jack Rated Output/Impedance /
ヘッドホン出力/インピーダンス
CD, etc. 40 mV, 8 ohms
. . . . . . . . . . . . . . . .
200 mV/100 ohms
Frequency Response / 周波数特性
CD, etc. 10 Hz to 100 kHz, MAIN L/R
. . . . . . . . . . . . .
0/-3.0 dB
RIAA Equalization Deviation / RIAA偏差
PHONO MM, 20 Hz to 20 kHz
. . . . . . . . . . . . . . . . . .
0 ± 0.5 dB
Speaker/ Head Phone Tone Control Characteristics / トーンコントロール
FRONT, CENTER SUBWOOFER
BASS Boost/Cut (50 Hz)
. . . . . . . . . . . . . . .
+6 dB/-6 dB
Turnover Frequency
. . . . .
125 Hz/350 Hz/500 Hz
TREBLE Boost/Cut (20 kHz)
. . . . . . . . . . . . . .
+6 dB/-6 dB
Turnover Frequency
. . . .
2.5 kHz/3.5 kHz/8.0 kHz
Manual Graphic Equalizer / マニュアルGEQ
FRONT, CENTER, SURROUND, SURROUND BACK, PRESENCE
Frequency
. . . . . . . . . . . .
63/125/250/500/1k/2k/4k/8k/16k Hz
Boost/Cut
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
+6 dB/-6 dB
Q
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2
Step
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
0.5
YPAO (YAMAHA Parametric Room Acoustic Optimizer)
f = 63 Hz to 16 kHz
. . . . . . . . . . . . . . .
+6 dB/-20 dB (10 Band)
Cross Over Characteristics / クロスオーバー特性
SUBWOOFER OUT
. . . .
40/60/80/90/100/110/120/160/200 Hz
Cinema Equalizer / シネマイコライザー
High Shelving Filter
Frequency
. . . . . . . . . . . . . . . .
1.0 kHz to 12.7 kHz
Boost/Cut
. . . . . . . . . . . . . . . . . . . . . .
+6 dB/-9 dB
Parametric Equalizer
Frequency
. . . . . . . . . . . . . . . .
1.0 kHz to 12.7 kHz
Boost/Cut
. . . . . . . . . . . . . . . . . . . . . .
+6 dB/-9 dB
Total Harmonic Distortion (20 Hz to 20 kHz) / 全高調波歪率
PHONO MM to REC OUT (1 V)
. . . . . . . . . . . . .
0.01 % or less
CD, etc. to PRE OUT MAIN L/R (1 V)
. . . . . . .
0.005 % or less
FRONT/CENTER IN to SP OUT L/C/R
J model (85 W/6 ohms)
. . . . . . . . . . . . . . . .
0.008 % or less
U, C, R, T, K, A, B, G models (85 W/8 ohms)
. . .
0.005 % or less
Signal to Noise Ratio (IHF-A Network) / S/N比
PHONO MM (Input shorted, Stereo)
J model (2.5 mV)
. . . . . . . . . . . . . . . . . . . . . .
80 dB or more
U, C, R, T, K, A, B, G models (5 mV)
. . . . . . .
86 dB or more
CD, etc. (Input shorted, Straight, 200mV)
. . . . .
97 dB or more
CD, etc. (Input shorted, Pure Direct, 200mV)
. .
98 dB or more
Residual Noise (IHF-A Network) / 残留ノイズ
MAIN L/R SP OUT
. . . . . . . . . . . . . . . . . . . . . . .
150 µV or less
Channel Separation / チャンネルセパレーション
PHONO MM (Input shorted)
1 kHz
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
70 dB or more
10 kHz
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
60 dB or more
CD, etc. (Input 5.1 kΩ shorted)
1 kHz
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
70 dB or more
10 kHz
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
60 dB or more
Muting / ミューティング
............................
- ∞

Yamaha RX-Z9 Specifications

General

Package weight	34110 g
Package depth	470 mm
Package height	211.13 mm
Receiver type	Surround
RMS rated power	1290 W
Pre-out connectivity	Yes
Audio output channels	9.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.005 %
Dynamic power per channel (4 Ohm)	340 W
Dynamic power per channel (8 Ohm)	210 W
Power output per channel (1KHz@8 Ohm)	170 W
RS-232 ports	1
12V trigger ports quantity	2
Speakers connectivity type	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Damping factor	200
Volume control	Rotary
Number of products included	1 pc(s)
S-Video inputs quantity	8
Component video (YPbPr/YCbCr) in	6
Ethernet LAN	No
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Preset stations quantity	40
THX-certified	THX Ultra2
Power consumption (standby)	1 W

Weight and Dimensions

Depth	471 mm
Width	435 mm
Height	211 mm
Weight	30000 g
