Yamaha T135SE User Manual

4-58
ENG
w
r
y
u
t
e
0
q
8
9
8
7
6
5
3
2
4
1
12 Nm (1.2 m•kg, 9.0 ft•lb )
10 Nm (1.0 m•kg, 7.2 ft•lb )
18 Nm (1.8 m•kg, 13 ft•lb )
E
E
E
E
LS
SHIFT SHAFT
EASF0032
SHIFT SHAFT
1
Shift pedal
2
Washer
3
Spring
4
Shift fork guide bar
5
Shift guide
6
Pawl holder
7
Guide
8
Washer
9
Thrust bearing
0
Dowel pin
q
Shift shaft
w
Shift lever assembly
e
Stopper lever spring
r
Stopper lever assembly
t
Collar
y
Plate
u
Shift drum segment
