ELEC
COOLING SYSTEM
8-41
NOTE:
9
Before troubleshooting, remove the following
part(s):
1. side cowlings (left and right)
2. center panel (lower)
3. rear cowling (right)
4. coolant
9
Troubleshoot with the following special service
tool(s).
TROUBLESHOOTING
Check:
1. fuse
2. battery
3. main switch
4. fan motor
5. fan motor relay
6. thermo sensor
7. wiring harness
(of the entire cooling system)
EAS00738
1. Fuse
9
Check the fuse for continuity.
Refer to “CHECKING THE FUSE” in chapter
3.
9
Is the fuse OK?
YES NO
Replace the fuse.
EAS00739
2. Battery
9
Check the condition of the battery.
Refer to “CHECKING AND CHARGING THE
BATTERY” in chapter 3.
9
Is the battery OK?
YES NO
9
Clean the battery
terminals.
9
Recharge or
replace the bat-
tery.
Pocket tester
90890-03112
Digital circuit tester
90890-03174
Minimum open-circuit voltage
12.8 V or more at 20 ° C (68 ° F)
9
The radiator fan motor fails to turn.
Replace the main
switch.
EAS00783
3. Main switch
9
Check the main switch for continuity.
Refer to “CHECKING THE SWITCHES”.
9
Is the main switch OK?
YES NO
To Next Page
