CHK
ADJ
3-41
CHECKING AND LUBRICATING THE CABLES/
LUBRICATING THE LEVER AND PEDALS/
LUBRICATING THE SIDESTAND/LUBRICATING THE CENTERSTAND
EAS00170
CHECKING AND LUBRICATING THE
CABLES
The following procedure applies to all of the
inner and outer cables.
w
Damaged outer cable may cause the cable to
corrode and interfere with its movement.
Replace damaged outer cable and inner
cables as soon as possible.
1. Check:
9
outer cable
Damage
→
Replace.
2. Check:
9
cable operation
Rough movement
→
Lubricate.
NOTE:
Hold the cable end upright and pour a few drops
of lubricant into the cable sheath or use a suit-
able lubricating device.
EAS00171
LUBRICATING THE LEVER AND PEDALS
Lubricate the pivoting point and metal-to-metal
moving parts of the lever and pedals.
EAS00172
LUBRICATING THE SIDESTAND
Lubricate the pivoting point and metal-to-metal
moving parts of the sidestand.
EAS00173
LUBRICATING THE CENTERSTAND
Lubricate the pivoting point and metal-to-metal
moving parts of the centerstand.
Recommended lubricant
Engine oil or a suitable cable
lubricant
Recommended lubricant
Lithium-soap-based grease
Recommended lubricant
Lithium-soap-based grease
Recommended lubricant
Lithium-soap-based grease
