CHAS
FRONT BRAKE
7-27
1
2
1
1
3. Check:
9
brake master cylinder reservoir
1
Cracks/damage
→
Replace.
9
brake master cylinder reservoir diaphragm
2
Damage/wear
→
Replace.
4. Check:
9
brake hose
1
Cracks/damage/wear
→
Replace.
EAS00598
ASSEMBLING AND INSTALLING THE
FRONT BRAKE MASTER CYLINDER
w
99
Before installation, all internal brake com-
ponents should be cleaned and lubricated
with clean or new brake fluid.
99
Never use solvents on internal brake com-
ponents.
1. Install:
9
brake master cylinder
1
NOTE:
9
Install the brake master cylinder holder with the
mark facing up.
9
Adjust the brake master cylinder to the proper
angle.
9
First, tighten the upper bolt, then the lower bolt.
Recommended brake fluid
DOT 3 or 4
11 Nm (1.1 m·kg, 8.0 ft·lb)
