EAU13445
Catalytic converters
This vehicle is equipped with catalytic
converters in the exhaust system.
EWA10862
The exhaust system is hot after
operation. To prevent a fire hazard
or burns:
G Do not park the vehicle near
possible fire hazards such as
grass or other materials that
easily burn.
G Park the vehicle in a place
where pedestrians or children
are not likely to touch the hot
exhaust system.
G Make sure that the exhaust
system has cooled down befo-
re doing any maintenance
work.
G Do not allow the engine to idle
more than a few minutes. Long
idling can cause a build-up of
heat.
ECA10701
Use only unleaded gasoline. The
use of leaded gasoline will cause
unrepairable damage to the cataly-
tic converter.
EAU13861
Seat
To remove the seat
1. Insert the key into the seat lock,
turn it counterclockwise, and
then pull the seat off.
1. Seat lock
2. Unlock
To install the seat
Insert the projections on the front of
the seat into the seat holders, push
the rear of the seat down to lock it in
place, and then remove the key.
NOTICE
WARNING
INSTRUMENT AND CONTROL FUNCTIONS
3-16
3
56P-F8199-E0 30/6/10 09:24 Página 34

Yamaha TENERE XT660Z Specifications

General

Displacement	660cc
Bore x Stroke	100.0 mm x 84.0 mm
Compression Ratio	10.0:1
Fuel System	Fuel Injection
Ignition	TCI
Starter System	Electric
Transmission	5-speed
Final Drive	Chain
Front Tire	90/90-21
Rear Tire	130/80-17
Seat Height	895 mm
Wet Weight	206 kg
Fuel Tank Capacity	23 liters
Lubrication System	Dry sump
Front Suspension Travel	210 mm
Rear Suspension Travel	200 mm
Wheel Base	1, 505 mm
Minimum Ground Clearance	260 mm
Engine Type	Liquid-cooled, 4-stroke, single cylinder, SOHC, 4-valves
Front Suspension	Telescopic fork
Rear Suspension	link suspension
Front Brake	Dual disc
Rear Brake	Single disc
Maximum Power	35.0 kW (48PS) @ 6, 000 rpm
