Yamaha VF175 - Optional Items; Remote Control Box

Components
27
EMU46731
Optional items
The following items are available from your Yamaha dealer. For details, consult your Yamaha
dealer.
EMU40611
Remote control box
The remote control box is equipped with the
remote control lever and electrical switches.
TRIP TIME BATT
Km/h
knot
mph
km
mile
SPEED
YAMAHA
set
mode
SET MODE
SET MODE
1
6
2453
10987
1. Remote control box (side mount type)
2. Remote control box (binnacle mount type)
3. Switch panel (for use with side-mount type)
4. Switch panel (for use with binnacle type)
5. Tilt support shaft
6. Digital tachometer
7. Digital speedometer
8. Fuel management meter
9. 6Y8 Multifunction tachometer
10.6Y8 Multifunction speed & fuel meter
1. Power trim and tilt switch
2. Remote control lever
3. Free accelerator button
4. Engine shut-off switch
5. Throttle friction adjuster
6. Neutral interlock trigger
ZMU07022
1
2
3
5
4
6
