Yamaha VF175 - Checks after Starting Engine; Cooling Water

Operation
59
4. Turn the main switch to the “ ”
(start) position, and hold it for a maxi-
mum of 5 seconds.
5. Immediately after the engine starts, re-
lease the main switch to return it to the
“” (on) position. NOTICE: Never turn
the main switch to “ ” (start) while
the engine is running. Do not keep the
starter motor turning for more than 5
seconds. If the starter motor is turned
continuously for more than 5 seconds,
the battery will be quickly discharged,
thus making it impossible to start the
engine. The starter can also be dam-
aged. If the engine will not start after 5
seconds of cranking, return the main
switch to “ ” (on), wait 10 seconds,
then crank the engine again.
[ECM00193]
EMU36511
Checks after starting engine
EMU41361
Cooling water
Check for a steady flow of water from the
cooling water pilot hole. A continuous flow of
water from the cooling water pilot hole shows
that the water pump is pumping water
through the cooling water passages.
TIP:
When the engine is started, there may be a
slight delay before water flows from the cool-
ing water pilot hole.
ZMU07031
ON
OFF
ZMU06927
ON
OFF
ZMU07032
ON
START
ZMU06928
ON
START
