Components
25
EMU46731
Optional items
The following items are available from your Yamaha dealer. For details, consult your Yamaha
dealer.
EMU40611
Remote control box
The remote control box is equipped with the
remote control lever and electrical switches.
TRIP TIME BATT
Km/h
knot
mph
km
mile
SPEED
YAMAHA
set
mode
SET MODE
SET MODE
5
241 3
876
9
ZMU08522
1. Remote control box (side mount type)
2. Remote control box (binnacle mount type)
3. Switch panel (for use with side-mount type)
4. Switch panel (for use with binnacle type)
5. Digital tachometer
6. Digital speedometer
7. 6Y8 Multifunction tachometer
8. 6Y8 Multifunction speed & fuel meter
9. Tiller handle
1. Power trim and tilt switch
2. Remote control lever
3. Free accelerator button
4. Engine shut-off switch
ZMU07022
1
2
3
5
4
6
