Yamaha Wolverine RMAX - Headlights

9-56
9
4. Turn on the main switch, start the engine,
and turn on the electrical circuit in ques-
tion to check if the device operates. If the
fuse blows again immediately, have a
Yamaha dealer check the electrical sys-
tem.
5. Install the hood.
EBU39550
Headlights
This model is equipped with LED headlights.
There are no user replaceable bulbs. If one or
more headlights do not come on, check for a
loose connection, check the headlight fuse,
and then have a Yamaha dealer check the ve-
hicle.
TIP
 When the headlights are set to low beam,
the outer two headlights come on.
 When the headlights are set to high beam,
all four headlights come on.
Specified fuses:
Main fuse:
50.0 A
Fuel injection system fuse:
10.0 A
Headlight fuse:
7.5 A
Ignition fuse:
15.0 A
Auxiliary DC jack fuse:
10.0 A
Signaling system fuse:
7.5 A
Four-wheel-drive motor fuse:
7.5 A
Radiator fan motor fuse:
30.0 A
ETV fuse:
10.0 A
Accessory fuse:
20.0 A
Backup fuse:
7.5 A
EPS fuse:
40.0 A
