Yamaha Wolverine RMAX - Vehicle Description and Controls; Vehicle Views and Components

4-1
4
EBU31170
DESCRIPTION
EBU31180
Left view
1 2,3 4 65
89 71011
1. Winch (YXE10WPZM)
2. Fuses
3. Battery
4. Air filters
5. Seat belt
6. Shoulder bolster
7. Door
8. Engine oil tank
9. Coolant reservoir
10.Brake fluid reservoir
11.Front shock absorber assembly
