Controls and instruments
The vehicle you have purchased may differ slightly from those shown in the figures of this manual.
1 3 5672 4
8
9
7
7
10
1112
71314
15
7
16
17
1. Steering wheel
2. Multi-function meter unit
3. Main switch
4. D-mode knob (YXE10WPZM)
5. Winch switch (YXE10WPZM)
6. Auxiliary DC jack
7. Storage compartment
8. Passenger handhold
9. Glove compartment
10.USB jack (YXE10WPZM)
11.Drive select lever
12.Parking brake lever
13.Accelerator pedal
14.Brake pedal
15.Steering wheel position adjusting lever
16.On-Command drive knob
17.Light switch
