6 Main switch
7 Battery
8 Main fuse
19 Igniter unit
24 Reset coupler
25 Speed sensor
37 Front brake light switch
41 Horn switch
42 Turn signal switch
43 Hazard switch
44 Rear brake light switch
45 Horn
46 Turn signal relay
47 Hazard relay
51 Front turn signal light (Left)
52 Front turn signal light (Right)
53 Rear turn signal light (Left)
54 Rear turn signal light (Right)
55 Tail/brake light
58 Turn signal indicator light
61 V-belt indicator light
62 Engine oil change indicator light
63 Clock
64 Speedometer
65 Water temperature gauge
66 Fuel gauge
67 Thermo unit (Water temperature)
68 Fuel level sender
70 Backup fuse
71 Signal fuse
73 Ignition fuse
75 Hazard fuse
SIGNAL SYSTEM
