Yamaha XP500 2002 - Troubleshooting

–30–
SIGNAL SYSTEM
ELEC
EAS00749
3. Main switch
S Check the main switch for continuity.
Refer to “CHECKING THE SWITCHES”.
S Is the main switch OK?
YES NO
Replace the main
switch.
YES
NO
4. Wiring
S Check the entire signal system’s wiring.
Refer to “CIRCUIT DIAGRAM”.
S Is the signaling system’s wiring properly
connected and without defects?
Properly connect or
repair the signal
system’s wiring.
Check the condition
of each of the signal
system’s circuits.
Refer to “CHECKING
THE SIGNALING
SYSTEM”.
EAS00795
EAS00739
2. Battery
S Check the condition of the battery.
Refer to “CHECKING THE BATTERY” in
CHAPTER 3. (Manual No.: 5GJ1-AE1)
Open-circuit voltage
12.8 V or more at 20_C
S Is the battery OK?
YES NO
S Clean the battery
terminals.
S Recharge or
replace the battery.
NOTE:
EAS00738
1. Main, signal, hazard and ignition fuses
S Check the main, signal, hazard and ignition
fuses for continuity.
Refer to “CHECKING THE FUSES” in
CHAPTER 3. (Manual No.: 5GJ1-AE1)
S Are the main, signal, hazard and ignition
fuses OK?
YES NO
Replace the fuse (-s).
EAS00794
TROUBLESHOOTING
S Any of the following fail to come on: turn
signal light, brake light, hazard or indica-
tor light.
S The horn fails to sound.
Check:
1. Main, signal and ignition fuses
2. Battery
3. Main switch
4. Wiring connections
(of the entire signal system)
S Before troubleshooting, remove the following
part(-s):
1) Front cowling
2) Handlebar cover
S Troubleshoot with the following special tool(-s).
Pocket tester
90890-03112
