SPECIFICATIONS
EAU26337
Dimensions:
Overall length:
2100 mm (82.7 in)
Overall width:
805 mm (31.7 in)
Overall height:
1160 mm (45.7 in)
Seat height:
810 mm (31.9 in)
Wheelbase:
1350 mm (53.1 in)
Ground clearance:
285 mm (11.22 in)
Minimum turning radius:
1900 mm (74.8 in)
Weight:
With oil and fuel:
121.0 kg (267 lb)
Engine:
Engine type:
Air cooled 4-stroke, SOHC
Cylinder arrangement:
Forward-inclined single cylinder
Displacement:
223.0 cm
3
(13.61 cu.in)
Bore
×
stroke:
70.0
×
58.0 mm (2.76
×
2.28 in)
Compression ratio:
9.50 :1
Starting system:
Electric starter
Lubrication system:
Wet sump
Engine oil:
Type:
YAMALUBE 4, SAE10W30 or SAE20W40
Recommended engine oil grade:
API service SE, SF, SG type or higher
Engine oil quantity:
Without oil filter element removal:
1.00 L (1.06 US qt) (0.88 Imp.qt)
With oil filter element removal:
1.10 L (1.16 US qt) (0.97 Imp.qt)
Air filter:
Air filter element:
Wet element
Fuel:
Recommended fuel:
Unleaded gasoline only
Fuel tank capacity:
8.8 L (2.32 US gal) (1.94 Imp.gal)
Fuel reserve amount:
2.0 L (0.53 US gal) (0.44 Imp.gal)
Carburetor:
Manufacturer:
MIKUNI
Type x quantity:
BST34 x 1
Spark plug(s):
Manufacturer/model:
NGK/DR8EA
Manufacturer/model:
DENSO/X24ESR-U
Spark plug gap:
0.6–0.7 mm (0.024–0.028 in)
Clutch:
Clutch type:
Wet, multiple-disc
Transmission:
Primary reduction system:
Spur gear
Primary reduction ratio:
73/22 (3.318)
Secondary reduction system:
Chain drive
Secondary reduction ratio:
45/15 (3.000)
Transmission type:
Constant mesh 6-speed
Operation:
Left foot operation
Gear ratio:
1st:
34/11 (3.090)
2nd:
30/15 (2.000)
3rd:
30/21 (1.428)
10° 30° 50° 70° 90°
110°
0°
130°F
YAMALUBE 4 (10W30)
or SAE 10W30
YAMALUBE 4 (20W40)
or SAE 20W40
–10° 0° 10° 20° 30°
40°
–20°
50°C
