Yamaha XT250 - Right View

Description
3-2
1
2
3
4
5
6
7
8
9
10
11
12
EAU10421
Right view
45
6
789
1 2 3
1. Spark arrester (page 7-17)
2. Fuses (page 7-33)
3. Battery (page 7-32)
4. Tool kit (page 7-2)
5. Front brake fluid reservoir (page 7-24)
6. Engine oil level check window (page 7-13)
7. Engine oil filler bolt (page 7-13)
8. Brake pedal (page 4-7)
9. Rear brake fluid reservoir (page 7-24)
