Yamaha XT250 - Replacing a Turn Signal Light Bulb

Periodic maintenance and adjustment
7-36
1
2
3
4
5
6
7
8
9
10
11
12
3. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
4. Install the lens by installing the
screws. NOTICE: Do not over-
tighten the screws, otherwise
the lens may break.
[ECA10682]
EAU24205
Replacing a turn signal light
bulb
1. Remove the turn signal light lens
by removing the screw.
2. Remove the burnt-out bulb by
pushing it in and turning it counter-
clockwise.
3. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
4. Install the lens by installing the
screw. NOTICE: Do not over-
tighten the screw, otherwise the
lens may break.
[ECA11192]
1. Brake/tail light bulb
1
1. Screw
2. Turn signal light lens
1
2
1. Turn signal light bulb
1
