CONTROLS
4-4
JW7
BRAKE PEDAL
Press down on the brake pedal to
stop the utility vehicle.
∫ Brake pedal
PARKING BRAKE
PEDAL
Press down on the parking brake
pedal whenever parking the utility
vehicle.
ç Parking brake pedal
TIP
Release the parking brake by
depressing the accelerator pedal.
The parking brake will automatically
release when the accelerator pedal
is depressed. If the main switch is
in the “ON” position, depressing
the accelerator may suddenly
cause the utility vehicle to move.
Death or serious personal injury
can result from failing to comply
with the safety instructions in this
manual.
HEADLIGHT/TAILLIGHT
ON POSITION
Turn the main switch all the way to
the right to the second ON position.
This will activate the headlights and
taillights.
Y-22a
C
Y-21a
B
E
F
1
/
2
Y-1641b
