PRE-OPERATION CHECKS
1
2
3
4
5
6
7
8
9
10
11
5-3
JW7
Avoid using gasoline blended with
methyl alcohol which can damage
fuel system parts.
ENGINE OIL
With the utility vehicle parked on
level ground, remove the dipstick
and make sure the engine oil is
between the MIN and MAX marks
(the crosshatched area on the end of
the dipstick).
å Oil level dipstick
∫ Maximum oil level
ç Safe operating range
If the oil level is below the MIN mark
on the dipstick, add oil through the
oil filler hole until the oil level is
between the MIN and MAX marks.
å Oil filler hole
Engine damage can result.
l Use care not to fill past the MAX
dipstick mark, and be sure no
foreign material enters the
crankcase.
l Use care not to get oil on the
starter belt.
TIP
The distance between the dipstick
marks represents approx. 1/2 L
(1/2 US qt) of oil.
TIP
Recommended engine oil
classification: API Service SE, SF, or
SG. Engine oils labeled “Energy
Conserving II” are recommended.
