Yamaha YTF2 - Fuel Gauge; Hour Meter

CONTROLS
1
2
3
4
5
6
7
8
9
10
11
4-5
JW7
FUEL GAUGE
The fuel gauge displays the fuel level
in the fuel tank. The fuel gauge will
only work when the key is in the ON
position.
å Fuel gauge
HOUR METER
The hour meter displays the total
number of hours the utility vehicle has
been run. Use the hour meter to deter-
mine when scheduled maintenance is
due.
å Hour meter
HORN SWITCH
The horn is located adjacent to the
brake pedal, and is activated by
depressing with your foot.
∫ Horn switch
TIP
It is advisable to sound the horn
when approaching blind corners.
CARGO BED
å Cargo bed
Y-901B
B
Y-1757
A
Y-2203
E
F
1
/
2
A
Y-2204
E
F
1
/
2
A
JW7-F8199-22_LIT_19626_16_05.qxd 5/9/13 4:28 PM Page 22
