CONTROLS
1
2
3
4
5
6
7
8
9
10
11
4-3
JW7
When the engine/oil warning light is
flashing while the key is on, there
may be a problem with the fuel
injection system, which may affect
performance, emissions and fuel
economy or cause damage to the
fuel injection system or engine.
If the light is flashing, do not
operate the vehicle. Contact your
Yamaha Service representative to
have the vehicle serviced.
å Engine/oil warning light
DRIVE SELECT LEVER
The drive select lever is used to shift
the utility vehicle into forward or
reverse. After coming to a complete
stop, move the lever to the desired
position.
Lever Position Car Movement
F FORWARD
R REVERSE
TIP
The reverse alarm will sound when
the drive select lever is turned to “R.”
ACCELERATOR PEDAL
The accelerator pedal controls the
vehicle’s speed.
Action Car Speed
Depress pedal Increase
Release pedal Decrease
å Accelerator pedal
