OPERATION
1
2
3
4
5
6
7
8
9
10
11
6-2
JW7
STOPPING
To stop the utility vehicle, gradually
press down on the brake pedal.
å Brake pedal
When the vehicle has come to a
stop, apply the parking brake pedal
and turn the main switch to “OFF.”
∫ Parking brake pedal
Do not hold the utility vehicle on
an incline with the accelerator –
use the brake. Transmission dam-
age can result.
LOADING
Cargo or a trailer can change the
stability and handling of a vehicle.
You must use common sense and
good judgment when carrying
cargo or towing a trailer. Keep the
following points in mind:
l Never exceed the weight limits
shown. An overloaded vehicle
can be unstable.
Y-65c
A
B
MAXIMUM LOADING LIMIT
l Vehicle Rated Capacity:
590 kg (1300 lb)
l Maximum Cargo Bed Capacity:
363 kg (800 lb)
l Maximum Towing Capacity:
454 kg (1000 lb)
l Maximum Tongue Weight:
68 kg (150 lb)
l Gross Vehicle Weight:
771 kg (1700 lb)
JW7-F8199-22_LIT_19626_16_05.qxd 5/9/13 4:28 PM Page 34
