5-16

FRONT FORK

REMOVING THE FRONT FORK

Order Part name Q'ty Remarks

Hold the machine by placing the suitable stand

under the engine.

Refer to "HANDLING NOTE".

Front wheel

Refer to "FRONT WHEEL AND REAR

WHEEL" section.

Front brake caliper

Refer to "FRONT BRAKE AND REAR

BRAKE" section.

Number plate

Refer to "SEAT, FUEL TANK AND SIDE

COVERS" section in the CHAPTER 4.

1Protector 1

2 Pinch bolt (upper bracket) 2 Only loosening.

3 Damper assembly 1

Loosen when disassembling the front fork.

Refer to removal section.

4 Pinch bolt (lower bracket) 2 Only loosening.

5 Front fork 1

21 Nm (2.1 m kg, 15 ft lb)

5 Nm (0.5 m kg, 3.6 ft lb)

7 Nm (0.7 m kg, 5.1 ft lb)
