Yamatake SDC40B Series - Page 137

Digital Controller SIO Driver
GP-Pro EX Device/PLC Connection Manual
137
8H)
• 1:1 Connection
• 1:n Connection
• The 5V output (Pin #6) on the GP-4107 is the power for the Siemens AG’s
PROFIBUS connector. Do not use it for other devices.
• In COM on the GP-4107, the SG and FG terminals are isolated.
Shield
Terminal block
Controller
Signal name
DA
DB
SG
Display
Terminal
resistance
150Ω ±5%
(more than
1/2W)
Terminal
resistance
150Ω ±5%
(more than
1/2W)
Pin
Signal name
NC
NC
GND(SG)
RS(RTS)
5V
NC
NC
FG
LINE(+)
LINE(-)
3
8
1
2
5
4
6
7
9
Shell
Display side
D-Sub 9pin (plug)
Shield
Terminal block
Controller
Signal name
DA
DB
SG
Display
Shield
Terminal block
Controller
Signal name
DA
DB
SG
Terminal
resistance
150Ω ±5%
(more than
1/2W)
Terminal
resistance
150Ω ±5%
(more than
1/2W)
Pin
Signal name
NC
NC
GND(SG)
RS(RTS)
5V
NC
NC
FG
LINE(+)
LINE(-)
3
8
1
2
5
4
6
7
9
Shell
Display side
D-Sub 9pin (plug)
