BEFORE YOU OPERATE
GM Series Operation Manual 31
12/05
3 – Upper Limit
4 – Lower Limit
3. Fully reinsert the dipstick.
4. Remove the dipstick. The oil level
should be between the upper
(Figure 5, (3)) and lower
(Figure 5, (4)) lines on the dipstick.
5. Add oil if necessary. See Adding
Engine Oil on page 31.
6. Fully reinsert the dipstick.
Adding Engine Oil
NOTICE
Prevent dirt and debris from contaminating
the engine oil. Carefully clean the dipstick
and the surrounding area before you
remove the cap.
1. Remove the yellow oil filler port cap
from filler port (Figure 5, (1)) on the
rocker arm cover and fill with engine oil.
2. Fill with engine oil to the upper limit
(Figure 5, (3)) on the dipstick
(Figure 5, (2)).
NOTICE
Never overfill the engine with engine oil.
3. Insert the dipstick fully to check the level.
NOTICE
Always keep the oil level between upper
and lower lines on the oil cap / dipstick.
4. Hand-tighten the filler port cap securely.
MARINE GEAR OR
SAIL-DRIVE OIL
Marine Gear Oil Specifications
Use marine gear oil that meets or exceeds
the following guidelines and classifications:
KM2P-1 (S), (G) or (GG):
• API Service Categories: CD or higher
• SAE Viscosity: #20 or #30
Sail-Drive Oil Specifications -
SD20
Refer to the Sail-Drive Operation Manual
for the procedure to fill or replace the drive
oil.
SD20:
• API Service Category: CC or higher
• SAE Viscosity: 10W-30
Engine Oil Capacity
1GM10 (V) (C) Full: 1.5 L (1.6 qt)
