Conversion of AWG to European Standards
CONVERSION OF AWG TO EUROPEAN STANDARDS
Conductor Size
(AWG)
Conductor Diameter
(mm)
Conductor Cross-sectional Area
(mm
2
)
25 0.455 0.163
24 0.511 0.205
23 0.573 0.259
22 0.644 0.325
21 0.723 0.412
20 0.812 0.519
19 0.992 0.653
18 1.024 0.823
17 1.15 1.04
16 1.29 1.31
15 1.45 1.65
14 1.63 2.08
13 1.83 2.63
12 2.05 3.31
11 2.30 4.15
10 2.59 5.27
9 2.91 6.62
8 3.26 8.35
73.6710.6
64.1113.3
54.6216.8
45.1921.2
35.8326.7
26.5433.6
17.3542.4
0 (1/0) 8.25 53.4
00 (2/0) 9.27 67.5
000(3/0) 10.40 85.0
0000 (4/0) 11.68 107.2
00000 (5/0) 13.12 135.1
000000 (6/0) 14.73 170.3
1.1 circular mil (CM) @ 0.0005067 mm
