PERIODIC MAINTENANCE
JH Series Operation Manual 83
12/05
Figure 17
Figure 18
Note: When replacing a used impeller
with a new one, the impeller
must have an M18x1.5 thread
(Figure 17, (1)). Turn the M18
screw side of the impeller to the
cover side and install
(Figure 18).
Puller B (option)
Part No. 129671-92100
Figure 19
Changing the Coolant
Coolant Hazard. Wear eye protection
and rubber gloves when you handle
engine coolant. If contact with the eyes
or skin should occur, flush eyes and
wash immediately with clean water.
Change the coolant every year.
Never mix different types and / or colors of
coolants.
Discard old coolant in an approved manner
according to environmental laws.
Note: If Long Life coolant is used,
replace coolant every 2 years.
AB
110 mm (4.33 in.) 140 mm (5.51 in.)
0004502
(A)
(B)
