GENERAL SERVICE INFORMATION
TNV DI Service Manual
4-23
Principal Engine Specifications
PRINCIPAL ENGINE SPECIFICATIONS
3TNV82A (~ EPA Tier2)
* Engine specifications without radiator.
** Engine oil capacity for a "Deep Standard" oil pan. Refer to the operation manual provided by the driven machine
manufacturer for the actual engine oil capacity of your machine.
*** May vary depending on application.
Engine Model 3TNV82A
Version CL VM
Type Vertical In-line Diesel Engine
Combustion System Direct Injection
Aspiration Natural
No. of Cylinders 3
Bore × Stroke 82 × 84mm
Displacement 1.331L
Continuous Rated Output
min
-1
1500 1800
kW 9.9 12.0
PS 13.5 16.3
Max. Rated Output (Net)
min
-1
1500 1800 2000 2200 2400 2600 2800 3000
kW 11.0 13.2 14.6 16.0 17.5 19.0 20.4 21.9
PS 14.9 17.9 19.9 21.8 23.8 25.8 27.8 29.8
High Idling min
-1
1600
± 25
1895
± 25
2180
± 25
2375
± 25
2570
± 25
2780
± 25
2995
± 25
3180
± 25
Engine Weight (Dry)
*with Flywheel Housing
138kg 128 kg
PTO Position Flywheel End
Direction of Rotation Counterclockwise Viewed From Flywheel End
Cooling System Liquid-Cooled with Radiator
Lubricating System Forced Lubrication with Trochoid Pump
Normal Oil Pressure at Rated
Engine Speed
0.34 - 0.49 MPa 0.39 - 0.54 MPa
Normal Oil Pressure at Low
Idle Speed
0.06 MPa
Starting System
Electric Starting (Starter Motor: DC12V (1.2 kW)) ***
Alternator: DC12V, 40A***
Recommended Battery Capacity: 12V, 55Ah*** (5h rating)
Dimensions (L × W × H)* 553 × 489 × 565 mm 528 × 489 × 565 mm
Engine Oil Pan Capacity**
5.5/3.6L
(Dipstick Upper Limit / Lower Limit)
Engine Coolant Capacity 1.8L Engine Only
Standard Cooling Fan 335mm O.D., 6 Blade Pusher-Type ***
Crank V-pulley dia./
Fan V-pulley dia.
φ120/ φ90mm *** φ110/ φ110mm ***
TNV_DI_SM_A4.book 23 ページ ２００７年１２月６日 木曜日 午前９時２３分
