GENERAL SERVICE INFORMATION
4-32
TNV DI Service Manual
Principal Engine Specifications
4TNV98T (~ EPA Tier2)
* Engine specifications without radiator.
** Engine oil capacity for a "Deep Standard" oil pan. Refer to the operation manual provided by the driven machine
manufacturer for the actual engine oil capacity of your machine.
*** May vary depending on application.
Engine Model 4TNV98T
Version CL VM
Type Vertical In-line Diesel Engine
Combustion System Direct Injection
Aspiration Turbocharged
No. of Cylinders 4
Bore × Stroke 98 × 110mm
Displacement 3.319L
Continuous Rated Output
min
-1
1500 1800
kW 37.9 45.6
PS 51.5 62.0
Max. Rated Output (Net)
min
-1
1500 1800 2000 2200 2400 2500
kW 41.9 50.4 50.7 55.5 60.3 62.5
PS 57.0 68.5 69.0 75.5 82.0 85.0
High Idling min
-1
1600 ± 25 1895 ± 25 2180 ± 25 2400 ± 25 2590 ± 25 2700 ± 25
Engine Weight (Dry)
*with Flywheel Housing
258 kg 245 kg
PTO Position Flywheel End
Direction of Rotation Counterclockwise Viewed From Flywheel End
Cooling System Liquid-Cooled with Radiator
Lubricating System Forced Lubrication with Trochoid Pump
Normal Oil Pressure at Rated
Engine Speed
0.29 - 0.39 MPa
Normal Oil Pressure at Low
Idle Speed
0.06 MPa
Starting System
Electric Starting (Starter Motor: DC12V (2.3 kW)) ***
Alternator: DC12V, 40A***
Recommended Battery Capacity: 12V, 64Ah ***
Dimensions (L × W × H)* 719 × 575 × 804mm
Engine Oil Pan Capacity**
10.5/6.0L
(Dipstick Upper Limit / Lower Limit)
Engine Coolant Capacity 4.2L Engine Only
Standard Cooling Fan 430mm O.D., 8 Blade Suction-Type ***
Crank V-pulley dia./
Fan V-pulley dia.
φ130/ φ130mm ***
