PERIODIC MAINTENANCE
SD60 Operation Manual 31
Anode Replacement
To minimize galvanic corrosion, the SD60 system has a sacrificial anode placed on the
foot of the sail drive.
This anode is not designed to accommodate other hardware or other excessive
electrical currents related to additional components or changes to the electrical AC
and DC systems on board the vessel.
This replaceable sacrificial anode capacity is for the drive only.
When a non-Aluminium propeller is installed, the non-Aluminium propeller must
have a additional replaceable sacrificial anode.
The anodes provide protection against corrosion under normal use.
1. Using a 6 mm “Allen” key, remove the
M8 screws of the anode.
Figure 23
2. Remove the anode of the foot.
If necessary, remove using a plastic
mallet. The anode is two piece type.
3. Place the new two piece anode on the
foot.
Figure 24
