DESCRIPTION OF PRODUCT
Parts description (Fig. A)
1. Top handle
2. Quick release clamp (fixed in screw) x 2
3. Lower handle
4. Transportation handle
5. Grass bag
6. Quick release clamp (curved head) x2
7. Rear safety flap
8. Cable clip x2
9. Switch box
10. Switch lever
Check the delivery parts (Fig. B)
Remove the machine from its packaging carefully and make sure that all of the following parts
are present:
a. Lawnmower with upper handle
b. Lower handle
c. Grass bag
d. Handle of grass bag
e. Quick release clamp (fixed in screw) x 2
f. Teeth clamp x 2
g. Quick release clamp (curved head) x2
h. Cable clip x2
i. Pull relief (for the power cable)
j. Instruction
WARNING:
If any parts are damaged or missing, do not operate this tool until
these parts have been replaced. Failure to heed this warning could result in serious
personal injury.
NOTE:
Always recycle the packaging in accordance with local recycling guidelines.
