16
INSTALLATION
Assemble the lower handle (Fig. C)
Attach the two tooth clamps to the lower handle.
Attach the lower handle to the lawnmower (Fig. D)
Install the lower handle to the lawnmower with the quick release clamps (with fixed in screw).
Make sure that the teeth of fixing gears interlock correctly.
Attach the top handle to the lawnmower (Fig. E)
Mount the top handle to the lower handle by using two quick release clamps (screw with
curved head)
NOTE: Ensure the assembly holes for the upper handle, the lower handle and the
rubber sleeve are in straight line, then to assemble the quick release clamps.
Fitting the cable clip (Fig. F)
Ensure that the cable clips supplied are used to fix the cable to the lower handle
Attach the grass bag (Fig. G & Fig. H & Fig. I)
1. Firstly Insert the grass bag handle into the groove of the grass bag.
(Fig. G)
2. Secondly Press the grass bag handle into the clip of the grass bag, and hear "click" to
indicate that the handle is in place.
3. Attach the grass bag to the frame by fixing the plastic P Clip hooks onto the sides an
bottom of the metal frame.
Lift the safety flap with one hand and hook in the grass bag. Release the safety flap to secure
the grass bag in position.
(Fig. H&I)
