A: From inside the Post Assemblies measure 4 ft 11 in (1.49 m) to mark the center of each Short Beam Assembly.
(F16.1)
B: With all four assemblers place one Large Roof Panel Assembly with Roof to Beam Brackets in front of the Post
Assemblies then raise it up so it is centered on the Long Beam Assembly. (F16.1)
Step 16: Attach Roof Panels to Frame
Part 1
F16.1
In front
of Post
Assembly
Long Beam
Assembly
Post
Assembly
Large Roof Panel
Assembly
Mark center
location
Mark center
location
x 3
Short Beam
Assembly
One assembler to support
roof panel(s) at all times until
secure
Short Beam
Assembly
Long Beam
Assembly
4 ft 11 in
(1.49 m)
