C: On the Small Roof Rafter Assembly just installed, centered and ush to the bottom of (2212), (2213) and
(2206), attach one Roof to Beam Bracket per board with one S10 in the bottom hole and one S34 in the top hole.
(F19.5)
x 3
F19.5
Parts removed
for clarity
Roof to
Beam
Bracket
(x3)
Flush
Attach to (2212), (2213) and
(2206)
(x3)
Hardware
3 x #8 x 1” Pan Screw
Step 19: Attach Final Roof Panel
Part 3
S34
S10
3 x #12 x 1-1/4” Pan Screw
3 x Roof to Beam Bracket
S10
S34
Components
To Next Page
