Step 21: Attach Roof Edges - Large Roof Assemblies
Hardware
F21.1
40 x #8 x 1” Roong Screw
A: On the bottom of each Large Roof Assembly place one Ridge Edge Middle so the holes line up with the holes
in the Middle Panels then attach with 10 #8 x 1” Roong Screws per Large Roof Assembly. (F21.1 and F21.2)
Components
4 x Ridge Edge Middle
#8 x 1” Roong
Screws
F21.2
Ridge
Edge
Middle
(1192) Mid
Fascia
(1192) Mid
Fascia
Ridge Edge
Middle
Top
Bottom
Bottom
Middle Panel
