Step 30: Attach Ridge Caps to Roof Panels
Part 3
E: At each Corner Roof Assembly and Large Roof Assembly connection, slide one Ridge Cap Middle over the
Ridge Clips, from the bottom up to the top, with cut end leading. Slide under Peak Cap Assembly. Attach with
two #8 x 3/4” Sheet Metal Screws per Ridge Cap Middle. (F30.9, F30.10 and F30.11)
Hardware
12 x #8 x 3/4” Sheet Metal Screw
Components
6 x Ridge Cap Middle
Ridge Clip 73.5
#8 x 3/4” Sheet Metal Screw
F30.9
Note: To help Ridge Caps
slide on easier use a
lubricant such as liquid soap.
F30.10
F30.11
Peak Cap
Assembly
Ridge Cap Middle
Ridge Cap Middle
Ridge
Cap
Middle
Ridge
Cap
Middle
Large Roof
Assembly
Corner Roof
Assembly
Corner Roof
Assembly
Corner Roof
Assembly
Corner Roof
Assembly
Large Roof
Assembly
Large Roof
Assembly
