6- #8 x 2-1/4” Wood Screw
1- Spacer Top
6- #8 x 2-1/4” Wood Screw
1- Spacer Top
Step 14: Attach Roof Panels - Large Roof
Part 3
F: On one Large Roof Rafter Assembly place one (936) Spacer ush to the outside edges and centred on
(1097) Top then attach with six #8 x 2-1/4” Wood Screws. (F14.5 and F14.6)
#8 x 2-1/4” Wood
Screws (x6)
Flush
(1097)
Top
(936)
Spacer
F14.6
1 x (936) Spacer
Wood Parts Hardware
6 x #8 x 2-1/4” Wood Screws
F14.5
