Yardistry YM12935 - Step 21: Attach Corner and Beam Caps; Corner Cap Installation

50 support@yardistrystructures.com
16- #8 x 3/4” Sheet Metal Screw
16- #8 x 3/4” Sheet Metal Screw
A: At each corner place one Corner Cap tight to Fascia Assemblies, push up so the bottom is tight to the bottom
of the assemblies then attach with four #8 x 3/4” Sheet Metal Screws per Corner Cap. (F21.1 and F21.2)
Hardware
16 x #8 x 3/4” Sheet Metal Screw
Components:
4 x Corner Cap
Corner
Cap
Fascia
Assembly
F21.1
F21.2
#8 x 3/4”
Sheet Metal
Screw
Large
Fascia
Assembly
Tight
x 3
Step 21: Attach Corner and Beam Caps
#8 x 3/4”
Sheet Metal
Screw
