Step 23: Secure Roof Peak Brackets
A: Tighten the six screws in Roof Peak Brackets then attach to Corner Rafters in the remaining holes with ten
#10 x 1-1/4” Pan Screws. (F23.1)
Hardware
10 x #10 x 1-1/4” Pan Screw
F23.1
Roof Peak
Bracket
Roof Peak
Bracket
Corner
Rafter
#10 x 1-1/4”
Pan Screw x 10
Corner
Rafter
Corner
Rafter
Corner
Rafter
