Step 24: Attach Ridge Caps to Roof Panels
A: Slide one Ridge Cap 85 over each Ridge Clip 85.25, with cut end leading, on each corner of the assembly
from the bottom up, lifting Peak Cap by pushing up the Peak Loop so Ridge Caps t under Peak Cap Long then
attach with two #8 x 3/4” Sheet Metal Screws per Ridge Cap 85. (F24.1, F24.2 and F24.3)
B: Tighten Loops to secure Roof Peak Set.
Hardware
8 x #8 x 3/4” Sheet Metal Screw
Components:
4 x Ridge Cap 85
Ridge
Cap 85
Ridge
Cap 85
Ridge Cap 85
Ridge Clip
85.25
#8 x 3/4” Sheet Metal Screw
Ridge
Cap 85
F24.1
F24.2
F24.3
x 3
Cut End
Folded
End
Note: To help Ridge Caps
slide on easier use a
lubricant such as liquid soap.
