Yardistry YM12935 - Step 26: Attach Twist Brackets; 45° Twist Bracket Installation

55 support@yardistrystructures.com
A: Measure 4-1/2” (11.43 cm) down from the inside of each post, place bottom of 45° Twist Bracket LT or 45° Twist
Bracket RT at measured location then attach to posts and LT Corner Rafters and RT Corner Rafters with four #10
x 1-1/4” Pan Screws per bracket. (F26.1 and F26.2)
Step 26: Attach Twist Brackets
Components:
2 x 45° Twist Bracket LT
2 x 45° Twist Bracket RT
45° Twist
Bracket
(LT or RT)
Hardware
16 x #10 x 1-1/4” Pan Screw
F26.1
Post
4-1/2”
#10 x 1-1/4”
Pan Screw
F26.2
Corner Rafter
(LT or RT)
11.43 cm
Post
