Top - (Make sure to square Centre Rafters to Rafter Top and Fascia)
Top
Centre Rafter
Y50000-633
#8 x 2½ Wood Screw X15
Y50000-675
of Fascias slope down
to install
Notice Angled end
Middle Rafter
down
Notice Angled end
of Rafter Top slopes
#8 x 2½ Wood Screw X4
Rafter Top
Top
Y50000-680
Y50000-678
Mid Fascia
Middle Rafter
Y50000-675
#8 x 2½ Wood Screw X2
HardwareWood Parts
F18.6
20 x #8 x 2-1/4” Wood Screw
10 x #8 x 2-1/2” Wood Screw
10 x (633) Centre Rafter
Flush
#8 x 2-1/2”
Wood Screws
#8 x 2-1/4”
Wood Screws
Step 18: Large Roof Assembly
Part 2
F18.5
(633) Centre
Rafter
Note notches
facing up
Flush
F18.7
D: Place ve (633) Centre Rafters over the pilot holes in (678) Mid Fascia and (680) Rafter Top so they are ush
to the top of each board, as shown in F18.5. Make sure (633) Centre Rafters are square to (678) Mid Fascia and
(680) Rafter Top then attach (680) Rafter Top to rafters with two #8 x 2-1/4” Wood Screws per rafter and (678) Mid
Fascia to rafters with one #8 x 2-1/2” Wood Screw per rafter. Repeat for second Large Roof Assembly. (F18.5,
F18.6, F18.7 and F18.8)
(633) Centre
Rafter
Flush
#8 x 2-1/2”
Wood Screws
(678) Mid
Fascia
F18.8
(678) Mid
Fascia
(675)
Middle
Rafter
(680)
Rafter
Top
(675)
Middle
Rafter
(633) Centre
Rafter
(680)
Rafter Top
