Figure 7g
Figure 7f
Figure 7d
Figure 7e
M8x45 (x2)
Pin
M5 X 12 X 2
6
M6 X 20 X 2
M5 X 12 X 38
7
M5 X 12 X 4
8
M8 X 45 X 2
9
Align the two side-plates with main body, assemble them
together by tightening the 38 M5x12 bolts and nuts. (See
Figure 7e
)
Put the rubber sheet under back plate. Assemble back
plate and rubber sheet with the unit. The rubber sheet is
designed to hang below the back plate of the bucket to
aid with collection (See
Figure 7f
)
Assemble two pins into the guard plate by tightening
M8x45 bolts and nuts. (See
Figure 7g
)
7.
8.
9.
10 mm
13 mm
18 mm
16 mm
7 mm
8 mm
X 2
M5x12 (x38)
Side-Plate
10 mm
13 mm
18 mm
16 mm
7 mm
8 mm
X 2
Figure 7h
Hang the tongues through the pins, secure it with bridge
pins. (See
Figure 7h
)
10.
Bridge Pin
Pin
M5x12 (x2)
2
1
3
4
2
1
3
4
M6x20 (x2)
10 mm
13 mm
18 mm
16 mm
7 mm
8 mm
10 mm
13 mm
18 mm
16 mm
7 mm
8 mm
X 2
M5x12 (x4)
Rubber Sheet
Back Plate
10 mm
13 mm
18 mm
16 mm
7 mm
8 mm
X 2
12
Power Sweeper
»
Operator’s Manual
Assembly
|
