28
• Position the chain so there is a loop at the back of the bar.
• Hold the chain in position on the bar and place the loop around the sprocket.
• Fit the bar flush agaist the mounting surface so that the bar studs are in the long shot
of the bar.
• Replace the chain cover.
• Replace the sleeve and chain cover lock bolt; use a hexagon ring spanner to rotate
bolt clockwise to tension. The bar should still be free to move for tension adjustment.
• Remove all slack from the chain by turning the chain tensioning bolt clockwise with a
hexagon ring spanner until the chain seats snugly against the bar with the drive links in
the bar groove.

NOTE: Make certain of direction of the chain.
!
MAINTENANCE
Chain rotation
Chain drive links
Cutters
Bar
groove
Chain drive links
