YASKAWA CDBR-2015B - Page 19

20
MAIN CIRCUIT
TERMINAL M6
2−LEAD WIRE OUTLET
1.38 (35) DIA RUBBER
BUSH
4−M6
MTG HOLE
3.94 (100) OR MORE
WIRE OUTLET 1.10 (28)
DIA RUBBER BUSH
3.94 (100) OR MORE
12.48 (317) 13.78 (350) 14.57 (370)
1.44 (36.5) 0.47 (12)
3.94 (100)
2.87 (73)
5.51 (140)
5.51 (140)
(59)
7.09 (180)
2.32
1.97 (50)
1.18 (30)
OR MORE
1.18 (30)
OR MORE
4.37 (111)
6.14 (156)
7.87 (200)
4.09
(104)
Fig. 4 Braking Unit Dimensions in inches (mm) CDBR−2110B
